Dolce Gusto Filling Packaging Machine

Category： Coffee Capsule Filling Sealing Machine
Dolce Gusto filling and sealing machines are custom-built to accurately fill capsules with coffee, milk, cocoa, sugar, and other materials, sealing them with foil.
They ensure reliable operation, high filling precision, strong seals, and easy maintenance, which helps extend product shelf life.
Dolce Gusto packaging is an emerging trend, offering capsules that hold more coffee than Nespresso and accommodating a variety of products like tea leaves, milk powder, and nutritional items.
INQUIRY EMAIL

1：Brief Introduce

Dolce Gusto has emerged as the most rapidly expanding model in recent years.
It offers greater capacity compared to Nespresso and features a dual-membrane design.
The machine is versatile and capable of filling capsules of various specifications.
It boasts a short filling cycle and high production output.
Fully automated, it supports large-scale production.
Users can select the number of filling heads based on their production requirements.
The touchscreen interface provides a user-friendly experience, displaying real-time production status, operational steps, filling methods, and more

2：Standard Functions of dolce gusto capsules filling machine：

Automatic Sort and feed the empty Dolce Gusto capsules.
Automatic Detect the empty cup whether capsules well loaded on the machine.
Servo motor filling ground coffee.
Clean the edge of the cup powder and press the powder.
NO-EDGE cutting and sealing inside film/paper filter
NO-EDGE cutting and sealing outside plastic/aluminum foil
Heat-sealed twice to ensure that the cup is well sealed.
Output to the conveyor

3.Characteristics:

Efficient Capsule Feeding System: Specially designed to reduce labor and operational costs.
Fully Automated Production Line: Equipped with advanced sensors to intelligently detect and respond to the presence or absence of cups, lids, coffee, air pressure, temperature, position, and more.
Reliable Control System: Powered by Omron for consistent performance, with options for other brands like Allen Bradley, Schneider, or Mitsubishi based on your preference.
Precision Filling: Servo motor-controlled filler ensures high accuracy with a stable error margin of just 0.2 grams.
Premium Components: Built with top-tier electronic and pneumatic parts from globally recognized brands in the USA, Japan, Germany, and France.
Durable Construction: Designed for longevity, with the majority of the machine made from stainless steel 304. All product-contact parts use food-grade SS304.
User-Friendly: The Dolce Gusto filling and sealing machine is simple to operate and maintain.

4.Technical parameters:

Model	HK-L4
Suitable product	Coffee, chocolate, tea, milk etc.
Capacity	160-200cups/min (adjustable)
Filling type	The Servo motor is a driven auger filler
Filling accuracy	±0.1g-0.15g
Sealing type	Pneumatically driven heat and seal, Omron precise temperature controller to adjust
Voltage	3 phase 220V @ 50/60hz - 3kw(by customer)
Dimension	650012002500mm
Weight	1800kg
Compressed air consumption	≥0.8Mpa／300L per minute

Discover our innovative DOLCE Gusto packaging machine—a custom-built solution designed to precisely fill and seal capsules with coffee,
milk, cocoa, sugar, and more. Experience reliable operation, high filling accuracy, and strong seals for extended shelf life. Interested? Get in touch to learn more.

Tags: DOLCE gusto filling packaging machine
