1kg Commercial Coffee Extractor

Category： Industrial Coffee Extraction Machine
• Perfect for R&D & Pilot Runs: Designed specifically for recipe testing, lab validation, and small-batch commercial production.
• 8-10 Min Ultra-Fast Cycle: Significantly faster than larger systems, yielding 2-3L of premium concentrate per batch.
• Seamless Scale-Up: Shares the exact same logic and Siemens PLC control as our 10kg models, making future capacity expansion effortless.
• Flexible Feeding Options: Choose between simple manual loading for frequent recipe changes, or automated feeding for continuous runs.
INQUIRY EMAIL

1.Introduction of 1KG Coffee Extractor

Our 1kg extraction system is engineered for coffee professionals who demand reliable, repeatable results.
Whether you are validating a new cold brew recipe, developing private-label RTD beverages, or running small-batch production,
this machine delivers the exact same extraction quality as our industrial-scale models.
It's not just a lab toy—it’s a production-grade system that ensures a seamless scale-up when your business is ready to grow.

2.Basic Parameters of 1kg Coffee Extractor

MODEL	HK-E1
BATCH CAPACITY	1kg Coffee Powder
MATERIAL	Full stainless stee Food-grade SUS304
SIZE	1400×950×1760 mm
WEIGHT	400kg
Capacity	~300L concentrate/24 hours
Extraction time	8-10min per batch
POWER	16KW
RATIO(Powder-to-liquid )	1:2–1:3 (adjustable)
PLC	Siemens PLC with Touch screen control
EXTRACTION METHOD	Cold Brew / Hot Extraction
WATER USAGE	Pure water/ Mineral water
FITER PRECISION	100 mesh filter (200/300 mesh optional)
Brix	8-12
WARRANTY PERIOD	2 years

3.Why Start with the 1kg Model? (The Business Case)

• Low Entry Barrier: Test your recipes, validate your market, and calculate accurate production costs before investing heavily in larger capacity equipment.
• True-to-Scale Data: Because it uses the same extraction logic, pressure parameters, and Siemens PLC as our 10kg and larger models,
the data you gather here translates perfectly to mass production.

• High Efficiency: With an ultra-fast 8-10 minute cycle time, you can quickly iterate through different coffee beans, grind sizes,

and temperatures in a single afternoon.

4.Core Features & Flexibility

• Dual Hot & Cold Brew Capability Easily switch between high-pressure hot espresso extraction and low-temperature cold brew. The programmable

system allows you to adjust temperature, pressure, and powder-to-liquid ratios (1:2 to 1:3) to hit your exact Brix/TDS targets.

• Flexible Coffee Feeding (Tailored to Your Workflow)

• Manual Feeding (Standard): Ideal for R&D labs and roasters who frequently change coffee beans and recipes. It's simple, easy to clean,

and requires no extra automation.

• Automatic Feeding (Optional): Upgrades the system to fully automated powder loading and puck ejection. Perfect for continuous,
small-batch commercial production with minimal labor.

5. Who Is This System Built For?

• Coffee Roasters developing new liquid coffee products.
•R&D Laboratories validating recipes before scaling up.
•Boutique Concentrate Producers focusing on high-end, small-batch runs.
• Cafes and Chains testing private-label offerings for their stores.

6.Ready to Move Forward? Let’s Run a Test.

We believe in proving our technology. Send us your coffee beans, and our engineering team will run a live extraction test,
sharing the yield data and flavor results directly with you. You can also request a live video demonstration to see the machine in action, or ask

for a customized quotation based on your specific feeding and filtration needs. We are here to help you find the perfect starting point.
